Probe type thermistor temperature sensor

Name: Probe type thermistor temperature sensor
SKU: N/A

RTD Types:Pt100,Pt1000,Pt500
Wire Configuration:Two-wire system,Three-wire system,Four-wire system
Lead Wire Materials:FEP (Fluorinated Ethylene Propylene),Silicone Rubber,PTFE (Polytetrafluoroethylene),PVC (Polyvinyl Chloride),Metal Braided High-Temperature Wire
Temperature Coefficient:TK = 3850 ppm/K
Self-Heating Coefficient:0.4 K/mW (at 0°C)
Accuracy Classes:1/10B Class: Tolerance ≤ ±0.03°C (0°C to +100°C)
1/3B Class: Tolerance ≤ ±0.10°C (0°C to +150°C)
A Class: Tolerance ≤ ±0.15°C (-50°C to +300°C)
B Class: Tolerance ≤ ±0.30°C (-70°C to +300°C)
Operating Current:100Ω: 0.3~1 mA
500Ω: 0.1~0.7 mA
1000Ω: 0.1~0.3 mA
Insulation Resistance:100 MΩ @ 500 V DC (measured at 20°C)
Pressure Resistance Standard:0.5 MPa

Send Inquiry

Download

Product Description

High-Precision Probe Type Thermistor Temperature Sensor Manufacturer And Supplier

As a leading Probe type thermistor temperature sensor manufacturer, we specialize in high-accuracy, industrial-grade sensors. With ISO 9001, CE, and RoHS certifications, our solutions deliver unmatched reliability across automotive, aerospace, medical, and automation sectors.

Probe type thermistor temperature sensor

Introduction to Our Probe Type Thermistor Temperature Sensor

Need precise temperature control in extreme conditions? Our Probe type thermistor temperature sensor combines platinum thin-film technology with IEC 60751 compliance. Designed for -200°C to +850°C ranges, it ensures ±0.01Ω accuracy and rapid 0.05-second response. Ideal for harsh environments, these sensors resist vibration (40g), impact (100g), and self-heating (0.4K/mW).

Why Choose Our Probe Type Thermistor Temperature Sensors?

Precision Engineering: 1/10B class accuracy (±0.03°C) for critical applications.
Customizable Designs: Tailor probe lengths (1.2–4.0mm), wire materials (FEP, PTFE), and configurations (2/3/4-wire).
Rugged Durability: Withstand extreme pressures (0.5 MPa) and temperatures.
Global Compliance: Meet IEC, CE, RoHS, and ISO standards.

Probe Type Thermistor Temperature Sensor Specifications

Parameter	Details
RTD Types	Pt100, Pt500, Pt1000
Wire Configuration	Two-wire, Three-wire, Four-wire
Lead Materials	FEP, Silicone Rubber, PTFE, PVC, Metal Braided
Accuracy Classes	1/10B (±0.03°C), 1/3B (±0.10°C), A (±0.15°C), B (±0.30°C)
Temperature Range	-200°C to +850°C
Response Time	≤0.05 seconds

Reference Selection Guide

Application	Recommended Model	Key Feature
Automotive Testing	PT-1000 (4-wire)	High vibration resistance, 3850ppm/K TCR
Medical Devices	PT-100 (FEP Insulation)	Medical-grade insulation, 0.1°C stability
Industrial Automation	PT-500 (Metal Braided)	0.5 MPa pressure tolerance, 100 MΩ insulation

Key Features

Ultra-Fast Response: 0.05-second reaction time for real-time monitoring.
Wide Compatibility: Works with PLCs, SCADA, and IoT systems.
Long-Term Stability: Drift ≤0.04% over 10,000 hours.
Vacuum-Sealed Options: Ideal for aerospace and semiconductor industries.

Applications

Industrial: Machinery health monitoring, HVAC control.
Medical: Sterilization equipment, incubators.
Automotive: Battery thermal management, exhaust systems.
Energy: Solar panel efficiency tracking, power grid safety.

Certifications & Quality Assurance

All of our sensors are designed and manufactured to adhere to the strict ISO 9001, RoHS, and CE standards. The ISO 9001 certification is a testament to our high - quality management system, ensuring consistency in production. RoHS compliance shows our commitment to environmental protection by limiting hazardous substances, and the CE mark guarantees conformity with European safety regulations. To further ensure reliability, our sensors undergo rigorous testing. Every single sensor has a 100% insulation resistance check, measuring at least 100 MΩ at 500V DC. Additionally, thermal cycling validation is carried out to verify their performance under extreme temperature changes, giving our customers peace of mind in using our products.

certificate

Packing & Delivery

Our Probe type thermistor temperature sensors are carefully packaged to ensure maximum protection during transit. Each sensor is placed in anti-static, vacuum-sealed packaging, creating a secure barrier against electrostatic discharge, moisture, dust, and oxidation. This safeguard maintains the sensors' integrity and functionality from the moment they leave our facility until they reach your hands. For bulk orders, we go the extra mile by providing customized crating. Tailored to the specific quantity and dimensions of your order, these crates offer enhanced protection and easy handling. Leveraging our partnerships with DHL and FedEx, we offer global delivery services. With lead times ranging from 7–14 days, you can expect your sensors to arrive promptly, no matter where you are in the world.

FAQ

Can I request custom probe lengths?
Yes! We offer probes from 1.2mm to 4.0mm.
What's the MOQ?
No minimum order—prototype or bulk production supported.
Do you provide certifications?
Yes, CE, RoHS, and ISO 9001 documents are included.
How durable are the sensors?
Tested to withstand 40g vibration and 100g impact.
What's the warranty period?
18-month warranty with lifetime technical support.

Contact Us for Precision Temperature Solutions!

Elevate your systems with Xi'an Tongzida's probe type thermistor temperature sensors. Email sales11@xatzd.com for quotes, samples, or technical queries. Let's engineer reliability together!
