Thin Film Platinum Resistor Pt100-SMD

Your Trusted Thin Film Platinum Resistor Pt100-SMD Manufacturer

As a leading manufacturer and supplier of high-precision temperature sensing solutions, Xi'an Tongzida Technology Co., Ltd. proudly offers our advanced Thin Film Platinum Resistor Pt100-SMD. Our expertise in microsensor manufacturing and special packaging technology ensures superior performance, reliability, and customization options to meet your specific needs.

Introduction to Thin Film Platinum Resistor Pt100-SMD

The Thin Film Platinum Resistor Pt100-SMD is a cutting-edge temperature sensing component designed for applications requiring precise measurement in compact spaces. This surface-mount device (SMD) combines the accuracy of platinum resistance thermometry with the convenience of modern electronics manufacturing processes.

Why Choose Our Thin Film Platinum Resistor Pt100-SMD?

1. Unparalleled Accuracy: With a temperature coefficient of 3850 ppm/°C, our sensors provide highly accurate readings across a wide temperature range.
2. Compact Design: The 3.2mm x 1.6mm x 0.7mm dimensions make it ideal for space-constrained applications.
3. Excellent Stability: Long-term resistance drift of ≤±0.06% after 1000 hours at 200°C ensures reliable performance over time.
4. Versatile Temperature Range: Measure from -50°C to +200°C with confidence.
5. Easy Integration: Tin alloy terminals and compatibility with reflow or wave soldering simplify manufacturing processes.





Specifications

Reference Selection

Features of Our Thin Film Platinum Resistor Pt100-SMD

• High accuracy and repeatability
• Fast response time
• Excellent long-term stability
• Wide temperature range
• Vibration and shock resistant
• RoHS and REACH compliant

Applications

Our Thin Film Platinum Resistor Pt100-SMD excels in various industries:

1. Industrial Process Control: Ensure precise temperature monitoring in manufacturing equipment.
2. Automotive Systems: Enhance thermal management in electric vehicle battery packs.
3. Medical Devices: Provide accurate temperature sensing for diagnostic equipment.
4. HVAC Systems: Improve energy efficiency in smart building controls.
5. Aerospace: Deliver reliable performance in extreme conditions.





Certificates

We maintain strict quality standards, evidenced by our ISO 9001, RoHS, and CE certifications. (Details available upon request)

Packing and Delivery

Our product sensors undergo meticulous packaging procedures designed to provide comprehensive protection during transit. Each sensor is carefully cushioned and sealed to safeguard against shocks, vibrations, and environmental factors that could potentially impact its integrity. We understand that every customer has unique needs, which is why we offer a diverse range of shipping options, enabling you to choose the service that best aligns with your timeline and budget. Additionally, for those with specific requirements, our custom packaging solutions are readily available, ensuring that your sensors arrive in perfect condition, ready for use.

Frequently Asked Questions

Q1: What is the minimum order quantity for the product?
A1: Our standard MOQ is 1000 units, but we're happy to discuss your specific requirements.

Q2: Can you provide custom calibration for specific temperature ranges?
A2: Yes, we offer tailored calibration services to meet your precise needs.

Q3: How does the product compare to wire-wound RTDs?
A3: Our thin film design offers faster response times and better vibration resistance than traditional wire-wound RTDs.

Q4: Are these sensors suitable for use in corrosive environments?
A4: While the standard model offers good chemical resistance, we can provide specialized coatings for harsh conditions.

Q5: What is the typical lead time for bulk orders?
A5: Standard lead time is 2-3 weeks, but we can expedite for urgent needs.

Contact Us

Ready to elevate your temperature sensing capabilities with our Thin Film Platinum Resistor Pt100-SMD? Our team of experts is standing by to answer your questions and provide tailored solutions. Reach out to us at sales11@xatzd.com to discuss how we can support your project's success.
