SMD Thin Film Pt100 Sensor

SMD Thin Film Pt100 Sensor Manufacturer And Supplier

Xi'an Tongzida Technology Co., Ltd. specializes in manufacturing high-performance SMD Thin Film Pt100 Sensors, combining cutting-edge microsensor technology with IEC60751 compliance. With ISO9001, RoHS, and CE certifications, our sensors deliver unmatched accuracy (±0.01Ω), stability (≤0.04% drift), and durability for industries like automotive, aerospace, and medical devices.

Why Choose Our SMD Thin Film Pt100 Sensor?

• Reliable Performance: Engineered to deliver consistent functionality, our SMD Thin Film Pt100 Sensor thrives in extreme conditions, operating seamlessly from -50°C to +200°C, making it a top choice for harsh industrial and outdoor environments.
• Long-Term Stability: With remarkable resilience, it ensures unwavering performance, maintaining ≤±0.06% resistance drift even after enduring 1,000 hours at 200°C, guaranteeing long - lasting reliability.
• Customizable Designs: We offer extensive flexibility, allowing you to tailor the product's dimensions, such as 3.2mm x 1.6mm, select lead materials, and choose suitable packaging to perfectly match your specific requirements.
• Global Compliance: Adhering to international benchmarks, our product meets IEC60751 for accuracy, AEC-Q200 for automotive safety, and ISO 13485 for medical applications, ensuring wide - ranging usability across industries.





Technical Specifications

Reference Selection Guide

Key Features

• Rapid Response: Boasting an incredibly fast 0.05s reaction time, our solution enables instantaneous real-time monitoring. This ensures that critical data is captured promptly, providing immediate insights for efficient decision-making across various applications.
• Robust Design: Engineered to endure the toughest conditions, its sturdy build can effortlessly withstand 40g vibrations and 100g shocks. This resilience makes it ideal for use in rugged environments where reliability is paramount.
• Plug-and-Play Integration: Designed for hassle-free implementation, it seamlessly integrates with reflow and wave soldering processes. This allows for quick and easy installation, reducing production time and enhancing overall efficiency.
• Multi-Industry Use: Pre-calibrated to meet diverse requirements, it offers seamless integration for OEM applications. Its versatility makes it a valuable asset across multiple industries, streamlining production and ensuring consistent performance.

Applications

Our SMD Thin Film Pt100 Sensor excels in:

• Automotive: EV battery thermal management, engine control.
• Medical: Sterilization systems, diagnostic equipment.
• Aerospace: Avionics, environmental control systems.
• Industrial: Process automation, HVAC monitoring.

Certifications & Quality Assurance

Our sensors are engineered with a steadfast commitment to quality and compliance, strictly adhering to RoHS, REACH, ISO9001, and various industry-specific standards. RoHS compliance ensures that our sensors are free from hazardous substances, safeguarding both users and the environment. REACH certification reflects our dedication to responsible chemical management, while ISO9001 validates our robust quality management system. In addition, we meet industry-specific requirements, guaranteeing suitability for diverse applications. To further uphold our high standards, each batch of sensors undergoes rigorous testing. This meticulous process ensures batch-to-batch consistency, providing our customers with reliable, high-performance sensors every time.

Packaging & Delivery

Our products are offered in two convenient packaging options to meet diverse customer needs. For enhanced protection and ease of handling, you can choose vacuum-sealed trays, which create an airtight environment to safeguard components from moisture, dust, and contaminants. Alternatively, the tape-and-reel packaging is ideal for automated assembly lines, ensuring seamless integration into your production processes. When it comes to shipping, we provide global delivery services. For standard orders, we are committed to a swift 15-day lead time, leveraging efficient logistics networks to ensure your products reach you promptly and in perfect condition.

FAQs

1. Can you customize lead materials?
   Yes! Choose platinum-nickel, silver-nickel, or pure platinum.
2. What's the minimum order quantity (MOQ)?
   MOQ starts at 1,000 units, with volume discounts.
3. Do you provide compliance documentation?
   Full traceability reports and certificates included.
4. How does the sensor handle thermal shock?
   Stable performance even under rapid temperature shifts.
5. Is technical support available?
   Free design integration guidance and datasheets provided.

Contact Us

Need a reliable partner for bulk SMD Thin Film Pt100 Sensors? Email sales11@xatzd.com for quotes, samples, or custom solutions.
