Material Testing Sensor

Name: Material Testing Sensor
SKU: N/A

Element Type:Platinum Resistance Thermistor
Element Dimensions:2.0mm x 2.3mm x 1.0mm,2.0mm x 4.0mm x 1.0mm
Lead Specifications:Length: 10 mm,Diameter: 0.2 mm
Lead Material: Platinum-nickel wire (optional: silver-palladium/platinum/pure silver)
Lead Tensile Strength:≥9 N
Insulation Resistance:100 MΩ at 20°C, >2 MΩ at 500°C
Temperature Coefficient (TCR):3850 ppm/°C
Operating Current:0.1–0.3 mA (self-heating effect to be considered)
Long-Term Stability:≤±0.04% resistance drift of R₀ (0°C reference) after 1000 hours at 50°C
Response Time:Water Flow (V=0.4 m/s):t₀.₅ = 0.05 s,t₀.₉ = 0.15 s;Airflow (V=2 m/s):t₀.₅ = 3 s,t₀.₉ = 10 s
Self-Heating Coefficient:0.4°C/mW (at 0°C)
Vibration Resistance:≥40g acceleration (frequency range: 10–2000 Hz)
Shock Resistance:≥100g acceleration (8 ms half-sine wave)
Packaging:Vacuum plastic packaging (other packaging formats available upon request)

Send Inquiry

Download

Product Description

Material Testing Sensor: Precision and Reliability for Your Testing Needs

At Xi'an Tongzida Technology Co., Ltd., we pride ourselves on being a leading manufacturer and supplier of high-quality Material Testing Sensors. Our progressed innovation and commitment to brilliance set us separated in the industry. We offer predominant exactness, strength, and customization choices to meet your particular testing necessities.

Material Testing Sensors

Introduction

In today's requesting mechanical scene, exact fabric testing is pivotal for guaranteeing item quality, security, and compliance. Our items are planned to give exact and solid information over a wide run of applications, from fabricating and development to aviation and R&D research facilities.

Why Choose Us?

Industry-leading expertise in sensor technology
Customizable solutions to fit your unique needs
Rigorous quality control and compliance with international standards
Comprehensive support from our experienced technical team
Competitive pricing for bulk orders

Specifications

Parameter	Value
Element Type	Platinum Resistance Thermistor
Element Dimensions	2.0mm x 2.3mm x 1.0mm, 2.0mm x 4.0mm x 1.0mm
Lead Specifications	Length: 10 mm, Diameter: 0.2 mm
Lead Material	Platinum-nickel wire (optional: silver-palladium/platinum/pure silver)
Temperature Coefficient (TCR)	3850 ppm/°C
Operating Current	0.1–0.3 mA
Long-Term Stability	≤±0.04% resistance drift of R₀ (0°C reference) after 1000 hours at 50°C

Reference Selection

Application	Recommended Model
Industrial Processes	MTS-2023-PN
Automotive Testing	MTS-4010-SP
Aerospace	MTS-2023-PT
R&D Laboratories	MTS-4010-PS

Features

High accuracy and stability for reliable measurements
Fast response time for real-time data acquisition
Excellent vibration and shock resistance
Wide temperature range coverage (-200°C to +850°C)
Customizable lead materials and dimensions
Vacuum packaging option for sensitive environments

Applications

Our Material Testing Sensors find applications across various industries:

Manufacturing quality control
Automotive performance testing
Aerospace material validation
Construction material analysis
Electronics thermal management
Oil and gas exploration
Materials research and development

By incorporating our sensors into your testing processes, you can ensure precise measurements and maintain high standards of quality control. Whether you're conducting durability tests, compliance checks, or product development, our products provide the accuracy and reliability you need.

Certificates

We maintain the highest standards of quality and compliance, including:

ISO 9001 Quality Management System
RoHS Certification
CE Certification

Packing and Delivery

Our sensors are carefully packaged to ensure safe transportation and maintain their precision. We offer flexible shipping options to meet your delivery requirements.

certificate

FAQ

Q: What is the typical lead time for bulk orders?
A: We typically process bulk orders within 2-3 weeks, depending on quantity and customization requirements.

Q: Do you offer calibration services?
A: Yes, we provide calibration certificates and offer recalibration services to ensure ongoing accuracy.

Q: Can these sensors be integrated with existing data acquisition systems?
A: Our sensors are designed for compatibility with most standard data acquisition systems. Our technical team can assist with integration questions.

Q: What warranty do you offer on your products?
A: We provide a standard 12-month warranty against manufacturing defects, with extended warranty options available.

Q: Do you offer sample testing before large-scale procurement?
A: Yes, we can provide sample units for testing and evaluation to ensure they meet your specific requirements.

Contact Us

Ready to enhance your material testing capabilities? Contact our sales team at sales11@xatzd.com to discuss your Material Testing Sensor needs and receive a customized quote for your bulk order.
