How to break through the pain points of vaccine cold chain temperature measurement? Tongzida ultra-low temperature PT1000 stable monitoring -200 ℃

In the cold chain transportation of vaccines and biological samples, temperature fluctuations exceeding ± 0.5 ℃ may lead to drug failure. Traditional sensors are prone to problems such as decreased insulation impedance and delayed response in environments below -80 ℃. The Tongzida Ultra Low Temperature Medical PT1000 sensor is specially developed for cold chain scenarios, with precise temperature measurement throughout the entire process from -200 ℃ ultra-low temperature storage to room temperature transportation, becoming a safety guarantee for medical cold chain.

H2: Extreme requirements for temperature sensors in medical cold chain

The storage and transportation of biological samples, vaccines, and other materials should cover temperatures ranging from -200 ℃ (liquid nitrogen storage) to+25 ℃ (normal temperature transportation). Sensors are required to have wide temperature adaptability, fast response (≤ 0.5s), moisture and vibration resistance (suitable for logistics environment), and accurate data transmission. The ultra-low temperature medical PT1000 sensor, with its initial resistance advantage of 1000 Ω, has far superior anti-interference ability compared to PT100, and can achieve long-distance transmission without compensating wires.

Ultra low temperature stability: Using silver palladium (AP) leads and vacuum packaging technology, the ultra-low temperature medical PT1000 sensor has an insulation impedance>100M Ω at -200 ℃ and a resistance drift of ≤ 0.04% after 1000h, far exceeding industry standards;

Quick response capability: With a thermal response time as low as 0.5s, real-time temperature fluctuations are captured to avoid drug loss caused by cold chain breakage;

Endurance to harsh environments: Anti vibration acceleration ≥ 40g, anti impact ≥ 100g, suitable for bumpy scenarios during cold chain vehicle transportation, with a protection level of IP67.

H2: Typical application case: Temperature measurement upgrade for vaccine cold chain logistics

A biopharmaceutical enterprise once caused a batch of COVID-19 vaccines to be scrapped due to the failure of its sensor at low temperature, resulting in a loss of more than one million yuan. After replacing the Tongzida ultra-low temperature medical PT1000 sensor, zero loss of vaccine transportation can be achieved through full temperature monitoring (accuracy ± 0.05 ℃). The stability of sensors directly determines the safety of the cold chain, and Tongzida's products give us complete peace of mind, "said the logistics manager of the enterprise

References

[1] What working conditions can the platinum thermistor PT1000 temperature sensor be applied to. Sohu, 2025
[2] What are the special requirements for PT1000 temperature sensors used in medical equipment KOBOLD, 2025
Click on Shentong Zida Ultra Low Temperature Medical PT1000 Sensor Sample, which includes customized calibration services for cold chain scenarios.

Author information

Author: Mr. Li from Tongzida Cold Chain Sensing Division
Title: Application Technology Director
Specializes in designing ultra-low temperature sensing solutions, leading multiple technological breakthroughs in medical cold chain sensors, and serving over 100 biopharmaceutical companies.

FAQ

Q1: Can the sensor adapt to the data docking of the cold chain monitoring platform?
A1: Supports mainstream protocols such as Modbus and 485, and can be directly integrated into existing monitoring systems without the need for additional development.
Q2: What is the service life of ultra-low temperature models?
A2: Under normal use, the lifespan is ≥ 3 years, and a 1-year warranty service is provided. Any malfunctions can be replaced free of charge.
